Configure a package in a lab Intune

Creating an Azure Application for Intune

This PowerShell script creates an Azure application with the necessary API permissions to interact with Microsoft Graph.

It also creates a service principal and grants admin consent.

The application will be used to manage (create/delete/get) Intune packages via PowerShell (IntuneWin32App module).

Create-Azure-IntuneWin32App.ps1

### Suppress module reinstallation errors and general warnings ###

$ErrorActionPreference = "SilentlyContinue"

### Only install Graph SDK if not already present ###

if (-not (Get-Module -ListAvailable -Name Microsoft.Graph)) {
    Install-Module Microsoft.Graph -Scope CurrentUser -Force -AllowClobber
}

### Connect to Microsoft Graph as Global Admin ###

Connect-MgGraph -Scopes "Application.ReadWrite.All", "DelegatedPermissionGrant.ReadWrite.All", "Directory.ReadWrite.All"

### Reset error handling for actual logic ###

$ErrorActionPreference = "Stop"

### Create the application with both redirect URIs for Mobile/Desktop ###

$app = New-MgApplication -DisplayName "Azure - IntuneWin32App" -PublicClient @{
    RedirectUris = @(
        "https://login.microsoftonline.com/common/oauth2/nativeclient",
        "urn:ietf:wg:oauth:2.0:oob"
    )
}

### Create a Service Principal for the application ###

$sp = New-MgServicePrincipal -AppId $app.AppId

### Get Microsoft Graph Service Principal (target API) ###

$graphSp = Get-MgServicePrincipal -Filter "DisplayName eq 'Microsoft Graph'"

### Define required delegated permissions ###

$delegatedPermissions = @(
    "DeviceManagementApps.ReadWrite.All",
    "DeviceManagementConfiguration.ReadWrite.All",
    "DeviceManagementManagedDevices.PrivilegedOperations.All",
    "DeviceManagementManagedDevices.ReadWrite.All",
    "DeviceManagementRBAC.ReadWrite.All",
    "DeviceManagementServiceConfig.ReadWrite.All",
    "Directory.Read.All",
    "Group.Read.All",
    "Group.ReadWrite.All",
    "openid",
    "User.Read"
)

### Resolve permission scope IDs ###

$requiredDelegatedPermissions = @()
foreach ($perm in $delegatedPermissions) {
    $match = $graphSp.Oauth2PermissionScopes | Where-Object { $_.Value -eq $perm }
    if ($match) {
        $requiredDelegatedPermissions += @{
            Id = $match.Id
            Type = "Scope"
        }
    } else {
        Write-Warning "Permission '$perm' not found in Microsoft Graph scopes."
    }
}

### Add permissions to the app registration ###

Update-MgApplication -ApplicationId $app.Id -RequiredResourceAccess @(
    @{
        ResourceAppId = $graphSp.AppId
        ResourceAccess = $requiredDelegatedPermissions
    }
)

### Grant admin consent using raw Graph REST API ###

$body = @{
    clientId    = $sp.Id
    consentType = "AllPrincipals"
    principalId = $null
    resourceId  = $graphSp.Id
    scope       = ($delegatedPermissions -join " ")
} | ConvertTo-Json -Depth 3

Invoke-MgGraphRequest -Method POST -Uri "https://graph.microsoft.com/v1.0/oauth2PermissionGrants" -Body $body -ContentType "application/json"

Write-Host "`nApp 'Azure - IntuneWin32App' created, both redirect URIs set, and admin consent granted successfully." -ForegroundColor Green

Creating a Win32App Package

Instead of using the Intune portal’s graphical interface to create and deploy an application package, this PowerShell script automates the entire process.

The PowerShell script Auto-DeployIntuneWin32App.ps1, located in the root folder LabIntune-ChromePackage, is designed to automate the deployment of Win32 applications in Microsoft Intune.

The root folder contains all the necessary files for running the script, including the config.json file for configuration (app name, app version, etc.), the IntuneWinAppUtil.exe executable for creating .intunewin packages, and the subfolders Package and Intunewin.

The Package folder contains the application’s source files, such as installation files or scripts, while the Intunewin folder is used to store the generated .intunewin packages.

This structured "directory" setup enables centralized management and simplifies the deployment process.

New-Item -Path "C:\LabIntune-ChromePackage\Apps\Intunewin" -ItemType Directory -Force
New-Item -Path "C:\LabIntune-ChromePackage\Apps\Package" -ItemType Directory -Force

Folder Structure

Install_ChromeBrowser.intunewin


GoogleChromeStandaloneEnterprise64.msi

Install_ChromeBrowser.ps1

Uninstall_ChromeBrowser.ps1

Auto-DeployIntuneWin32App.ps1

config.json

{
    "clientId":  "c5552704-11fd-4b02-9910-c2bba101e899",
    "tenantId":  "93bf5cc4-6277-44d9-bb70-57af85b6277e",
    "appName":  "[FRLAB] - Google Chrome 136.0.7103.49",
    "appDescription":  "Google Chrome",
    "publisher":  "Google",
    "appVersion":  "136.0.7103.49",
    "intunewinFileName":  "Install_ChromeBrowser",
    "installCommandLine":  "powershell.exe -ExecutionPolicy Bypass -File .\\Install_ChromeBrowser.ps1",
    "uninstallCommandLine":  "powershell.exe -ExecutionPolicy Bypass -File .\\Uninstall_ChromeBrowser.ps1",
    "iconPath":  "Apps\\Package\\chrome.png",
    "detection":  {
                      "type":  "MSI",
                      "productcode":  "{C0A67654-8811-318B-A81F-473E4F5DA8EB}",
                      "checkProductVersion":  false
                  },
    "intunewinFilePath":  "C:\\LabIntune\\LabIntune-ChromePackage\\Apps\\Intunewin\\Install_ChromeBrowser.intunewin"
}

Auto-DeployIntuneWin32App.ps1

### © Aaron Pescasio / www.apescasio.fr ###

### Function to handle errors ###

function Write-Log {
    param (
        [Parameter(Mandatory = $true)]
        [string]$Message,

        [Parameter(Mandatory = $false)]
        [ValidateSet("Info", "Warning", "Error", "Success")]
        [string]$Level = "Info"
    )

    $timestamp = Get-Date -Format "yyyy-MM-dd HH:mm:ss"
    $logMessage = "[$timestamp] [$Level] $Message"

    switch ($Level) {
        "Info" { Write-Host $logMessage -ForegroundColor Cyan }
        "Warning" { Write-Host $logMessage -ForegroundColor Yellow }
        "Error" { Write-Host $logMessage -ForegroundColor Red }
        "Success" { Write-Host $logMessage -ForegroundColor Green }
    }
}

### Function to check and install required modules ###

function Ensure-ModuleInstalled {
    param (
        [Parameter(Mandatory = $true)]
        [string]$ModuleName
    )

    if (-not (Get-Module -ListAvailable -Name $ModuleName)) {
        Write-Log "Installing module $ModuleName..." "Info"
        try {
            Install-Module -Name $ModuleName -Force -Scope CurrentUser
            Write-Log "Module $ModuleName installed successfully" "Success"
        }
        catch {
            Write-Log "Failed to install module $ModuleName : $_" "Error"
            throw "Impossible to install module : $ModuleName"
        }
    }
    else {
        Write-Log "Module $ModuleName already installed" "Info"
    }

    Import-Module $ModuleName
}

### Function to create the .intunewin package ###

function Create-IntuneWinPackage {
    param (
        [Parameter(Mandatory = $true)]
        [string]$SourcePath,

        [Parameter(Mandatory = $true)]
        [string]$SetupFile,

        [Parameter(Mandatory = $true)]
        [string]$OutputPath,

        [Parameter(Mandatory = $true)]
        [string]$IntuneWinAppUtilPath
    )

    if (-not (Test-Path $SourcePath)) {
        throw "The source path does not exist : $SourcePath"
    }

    if (-not (Test-Path $IntuneWinAppUtilPath)) {
        throw "IntuneWinAppUtil.exe does not exist : $IntuneWinAppUtilPath"
    }

    $sourceFilePath = Join-Path $SourcePath $SetupFile
    if (-not (Test-Path $sourceFilePath)) {
        throw "The installer file does not exist : $sourceFilePath"
    }

    if (-not (Test-Path $OutputPath)) {
        New-Item -Path $OutputPath -ItemType Directory -Force | Out-Null
        Write-Log "Output folder has been created : $OutputPath" "Info"
    }

    Write-Log "Creating the package .intunewin right now..." "Info"
    $processArgs = "-c ""$SourcePath"" -s ""$sourceFilePath"" -o ""$OutputPath"""

    try {
        $process = Start-Process $IntuneWinAppUtilPath -ArgumentList $processArgs -Wait -PassThru -NoNewWindow

        if ($process.ExitCode -ne 0) {
            throw "Package creation failed with this error code $($process.ExitCode)"
        }

        $intunewinFileName = [System.IO.Path]::GetFileNameWithoutExtension($SetupFile) + ".intunewin"
        $intunewinFilePath = Join-Path $OutputPath $intunewinFileName

        if (-not (Test-Path $intunewinFilePath)) {
            throw "The file .intunewin has not been created successfully : $intunewinFilePath"
        }

        Write-Log "Package .intunewin created successfully : $intunewinFilePath" "Success"
        return $intunewinFilePath
    }
    catch {
        Write-Log "Error during package creation : $_" "Error"
        throw "Error during package creation .intunewin"
    }
}

### Function to connect to Microsoft Graph ###

function Connect-ToMSGraph {
    param (
        [Parameter(Mandatory = $true)]
        [string]$ClientId,

        [Parameter(Mandatory = $true)]
        [string]$TenantId,

        [Parameter(Mandatory = $false)]
        [switch]$UseDeviceAuthentication = $true
    )

    try {
        Write-Log "Connecting to Microsoft Graph..." "Info"
        Connect-MSIntuneGraph -TenantId $TenantId -ClientId $ClientId
        Write-Log "Successfully connected to Microsoft Graph" "Success"
    }
    catch {
        Write-Log "Cannot connect to Microsoft Graph : $_" "Error"
        throw "Cannot connect to Microsoft Graph"
    }
}

### Function to deploy the application in Intune ###

function Deploy-IntuneApp {
    param (
        [Parameter(Mandatory = $true)]
        [string]$IntuneWinFilePath,

        [Parameter(Mandatory = $true)]
        [string]$AppName,

        [Parameter(Mandatory = $true)]
        [string]$AppDescription,

        [Parameter(Mandatory = $true)]
        [string]$Publisher,

        [Parameter(Mandatory = $false)]
        [string]$AppVersion = [string]::Empty,

        [Parameter(Mandatory = $true)]
        [string]$InstallCommandLine,

        [Parameter(Mandatory = $true)]
        [string]$UninstallCommandLine,

        [Parameter(Mandatory = $true)]
        [PSCustomObject]$DetectionSettings,

        [Parameter(Mandatory = $false)]
        [string]$Icon = [string]::Empty,

        [Parameter(Mandatory = $false)]
        [string]$Architecture = "x64",

        [Parameter(Mandatory = $false)]
        [string]$MinWindowsRelease = "W11_21H2"
    )

    if (-not (Test-Path $IntuneWinFilePath)) {
        throw "The file .intunewin does not exist : $IntuneWinFilePath"
    }

    try {
        Write-Log "Setting up the Detection Rule for $AppName" "Info"
        if ($DetectionSettings.type -eq "MSI") {
            $detectionRule = New-IntuneWin32AppDetectionRuleMSI `
                -ProductCode $DetectionSettings.productcode `
                -ProductVersionOperator "notConfigured"
        }
        elseif ($DetectionSettings.type -eq "File") {
            $detectionRule = New-IntuneWin32AppDetectionRuleFile `
                -Path $DetectionSettings.path `
                -FileOrFolder $DetectionSettings.fileorfolder `
                -Version $DetectionSettings.version `
                -Operator $DetectionSettings.operator `
                -Check32BitOn64System $DetectionSettings.check32biton64system
        }
        elseif ($DetectionSettings.type -eq "Registry") {
            $detectionRule = New-IntuneWin32AppDetectionRuleRegistry `
                -KeyPath $DetectionSettings.keypath `
                -ValueName $DetectionSettings.valuename `
                -Check32BitOn64System $DetectionSettings.check32biton64system `
                -DetectionType $DetectionSettings.detectiontype `
                -StringComparisonOperator $DetectionSettings.stringcomparisonoperator `
                -StringComparisonValue $DetectionSettings.stringcomparisonvalue `
                -VersionComparisonOperator $DetectionSettings.versioncomparisonoperator `
                -VersionComparisonValue $DetectionSettings.versioncomparisonvalue `
                -IntegerComparisonOperator $DetectionSettings.integercomparisonoperator `
                -IntegerComparisonValue $DetectionSettings.integercomparisonvalue
        }
        else {
            throw "Type of detection is not supported, only MSI / File / Registry works here and you selected : $($DetectionSettings.type)"
        }

        Write-Log "Setting up the requirement rule for $AppName" "Info"
        $requirementRule = New-IntuneWin32AppRequirementRule -Architecture $Architecture -MinimumSupportedWindowsRelease $MinWindowsRelease

        $returnCodes = @(
            New-IntuneWin32AppReturnCode -ReturnCode 0 -Type "success"
            New-IntuneWin32AppReturnCode -ReturnCode 1707 -Type "success"
            New-IntuneWin32AppReturnCode -ReturnCode 3010 -Type "softReboot"
            New-IntuneWin32AppReturnCode -ReturnCode 1641 -Type "hardReboot"
            New-IntuneWin32AppReturnCode -ReturnCode 1618 -Type "retry"
        )

        Write-Log "Deploying the actual package $AppName inside of the portal Intune..." "Info"
        $existingApp = Get-IntuneWin32App -DisplayName $AppName -ErrorAction SilentlyContinue

        if ($existingApp) {
            Write-Log "An application with the name '$AppName' already exists. Updating it right now..." "Warning"
            $app = Update-IntuneWin32App -ID $existingApp.id `
                -FilePath $IntuneWinFilePath `
                -DisplayName $AppName `
                -Description $AppDescription `
                -Publisher $Publisher `
                -AppVersion $AppVersion `
                -InstallExperience "system" `
                -RestartBehavior "suppress" `
                -DetectionRule $detectionRule `
                -RequirementRule $requirementRule `
                -ReturnCode $returnCodes `
                -InstallCommandLine $InstallCommandLine `
                -UninstallCommandLine $UninstallCommandLine `
                -Icon $Icon
            Write-Log "Application $AppName successfully updated (ID: $($app.id))" "Success"
        }
        else {
            $app = Add-IntuneWin32App -FilePath $IntuneWinFilePath `
                -DisplayName $AppName `
                -Description $AppDescription `
                -Publisher $Publisher `
                -AppVersion $AppVersion `
                -InstallExperience "system" `
                -RestartBehavior "suppress" `
                -DetectionRule $detectionRule `
                -RequirementRule $requirementRule `
                -ReturnCode $returnCodes `
                -InstallCommandLine $InstallCommandLine `
                -UninstallCommandLine $UninstallCommandLine `
                -Icon $Icon
            Write-Log "Application $AppName deployed successfully inside of the portal Intune (ID: $($app.id))" "Success"
        }

        return $app
    }
    catch {
        Write-Log "Failed to deploy the application inside of the portal Intune $AppName : $_" "Error"
        throw "Failed to deploy the application inside of the portal Intune"
    }
}

### Main function ###

function Main {
    $scriptRoot = if ($PSScriptRoot) {
        $PSScriptRoot
    } elseif ($MyInvocation.MyCommand.Path) {
        Split-Path -Parent $MyInvocation.MyCommand.Path
    } else {
        Get-Location
    }

    Write-Log "Using the root folder : $scriptRoot" "Info"

    $configPath = Join-Path $scriptRoot "config.json"
    $pathPackage = Join-Path $scriptRoot "Apps\Package"
    $pathIntunewin = Join-Path $scriptRoot "Apps\Intunewin"
    $intuneWinAppUtilPath = Join-Path $scriptRoot "IntuneWinAppUtil.exe"

    if (-not (Test-Path $configPath)) {
        Write-Log "The config.json does not exist : $configPath" "Error"
        exit 1
    }

    if (-not (Test-Path $intuneWinAppUtilPath)) {
        Write-Log "IntuneWinAppUtil.exe does not exist : $intuneWinAppUtilPath" "Error"
        exit 1
    }

    try {
        $config = Get-Content $configPath -Raw | ConvertFrom-Json
        Write-Log "Configuration imported successfully" "Success"
    }
    catch {
        Write-Log "Configuration has not been imported successfully : $_" "Error"
        exit 1
    }

    Ensure-ModuleInstalled -ModuleName "Microsoft.Graph.Intune"
    Ensure-ModuleInstalled -ModuleName "IntuneWin32App"

    try {
        $setupFile = "$($config.intunewinFileName).ps1"
        $intunewinFilePath = Create-IntuneWinPackage -SourcePath $pathPackage -SetupFile $setupFile `
                                                   -OutputPath $pathIntunewin -IntuneWinAppUtilPath $intuneWinAppUtilPath

        $configUpdated = $config | Select-Object *
        Add-Member -InputObject $configUpdated -MemberType NoteProperty -Name "intunewinFilePath" -Value $intunewinFilePath -Force
        $configUpdated | ConvertTo-Json | Set-Content $configPath

        $iconBase64 = [string]::Empty
        if ($config.iconPath -and (Test-Path (Join-Path $scriptRoot $config.iconPath))) {
            Write-Log "Importing the icon image from : $($config.iconPath)" "Info"
            $iconPath = Join-Path $scriptRoot $config.iconPath
            $iconBytes = [System.IO.File]::ReadAllBytes($iconPath)
            $iconBase64 = [System.Convert]::ToBase64String($iconBytes)
            Write-Log "Icon image converted to Base64 successfully" "Success"
        }
        else {
            Write-Log "Icon image not found or not specified correctly in configuration" "Warning"
        }

        Connect-ToMSGraph -ClientId $config.clientId -TenantId $config.tenantId -UseDeviceAuthentication

        $app = Deploy-IntuneApp -IntuneWinFilePath $intunewinFilePath `
                              -AppName $config.appName `
                              -AppDescription $config.appDescription `
                              -Publisher $config.publisher `
                              -AppVersion $config.appVersion `
                              -InstallCommandLine $config.installCommandLine `
                              -UninstallCommandLine $config.uninstallCommandLine `
                              -DetectionSettings $config.detection `
                              -Icon $iconBase64

        Write-Log "Deployment of $($config.appName) is a success" "Success"
    }
    catch {
        Write-Log "An error happened during the process : $_" "Error"
        exit 1
    }
}

### Execute the main script ###

Main

Install_ChromeBrowser.ps1

### © Aaron Pescasio / www.apescasio.fr ###

### Handle PowerShell 32-bit on 64-bit systems ###

If ($ENV:PROCESSOR_ARCHITEW6432 -eq "AMD64") {
    Try {
        &"$ENV:WINDIR\SysNative\WindowsPowershell\v1.0\PowerShell.exe" -File $PSCOMMANDPATH
    }
    Catch {
        Throw "Failed to start $PSCOMMANDPATH"
    }
    Exit
}

### Test and create the directory for installation logs ###

if (!(Test-Path "$($env:ProgramData)\Lab")) {
    New-Item -Path "$($env:ProgramData)\Lab" -ItemType "Directory" | Out-Null
}
if (!(Test-Path "$($env:ProgramData)\Lab\Intune")) {
    New-Item -Path "$($env:ProgramData)\Lab\Intune" -ItemType "Directory" | Out-Null
}

$date = Get-Date -UFormat "%Y%m%d-%H%M%S"
$errorCode = 0

### Start logging ###

Start-Transcript -Path "$($env:ProgramData)\Lab\Intune\$date-Install_Chrome.log" -Force

try {
    Write-Host "$((Get-Date).ToString('yyyy-MM-dd HH:mm:ss')) - Starting Google Chrome Install"

    # Execute the MSI installer without a graphical interface
    $result = Start-Process 'msiexec.exe' -ArgumentList "/I GoogleChromeStandaloneEnterprise64.msi /qn /norestart" -Wait -PassThru
    if ($result.ExitCode -ne 0) {
        throw "Installation failed with exit code $($result.ExitCode)"
    }

    Write-Host "$((Get-Date).ToString('yyyy-MM-dd HH:mm:ss')) - Google Chrome installation completed successfully"
}
catch {
    Write-Host "$((Get-Date).ToString('yyyy-MM-dd HH:mm:ss')) - Install in error: $($_.Exception.Message)"
    $errorCode = 1
}
finally {
    Stop-Transcript
}

Exit $errorCode

Uninstall_ChromeBrowser.ps1

### © Aaron Pescasio / www.apescasio.fr ###

### Search for Google Chrome ###

$SEARCH = 'Google Chrome'

### Retrieve installation information ###

$INSTALLED = Get-ItemProperty HKLM:\Software\Microsoft\Windows\CurrentVersion\Uninstall\* | Select-Object DisplayName, UninstallString
$INSTALLED += Get-ItemProperty HKLM:\Software\Wow6432Node\Microsoft\Windows\CurrentVersion\Uninstall\* | Select-Object DisplayName, UninstallString

### Search for the program ###

$RESULT = $INSTALLED | Where-Object { $_.DisplayName -ne $null -and $_.DisplayName -match $SEARCH }

### Create the log folder if necessary ###

if (!(Test-Path "$($env:ProgramData)\Lab")) {
    New-Item -Path "$($env:ProgramData)\Lab" -ItemType "Directory" -Force | Out-Null
}
if (!(Test-Path "$($env:ProgramData)\Lab\Intune")) {
    New-Item -Path "$($env:ProgramData)\Lab\Intune" -ItemType "Directory" -Force | Out-Null
}

$date = Get-Date -UFormat "%Y%m%d-%H%M%S"
$errorCode = 0

Start-Transcript -Path "$($env:ProgramData)\Lab\Intune\$date-Uninstall_Chrome.log" -Force

### Check if the program is found ###

if ($RESULT) {
    Write-Host "Program found. Starting the uninstallation..."

    # Uninstall Google Chrome
    if ($RESULT.UninstallString -like "msiexec*") {
        try {
            $ARGS = (($RESULT.UninstallString -split ' ')[1] -replace '/I', '/X ') + ' /q'
            Start-Process msiexec.exe -ArgumentList $ARGS -Wait
            Write-Host "Chrome has been uninstalled successfully."
        }
        catch {
            Write-Error "Error during uninstallation of MSI: $_"
            $errorCode = 1
        }
    } else {
        try {
            $UNINSTALL_COMMAND = (($RESULT.UninstallString -split '\"')[1])
            $UNINSTALL_ARGS = (($RESULT.UninstallString -split '\"')[2]) + ' /S'
            Start-Process $UNINSTALL_COMMAND -ArgumentList $UNINSTALL_ARGS -Wait
            Write-Host "Chrome has been uninstalled successfully."
        }
        catch {
            Write-Error "Error during uninstallation of MSI: $_"
            $errorCode = 1
        }
    }
} else {
    Write-Warning "Program '$SEARCH' not found in the device."
}

Stop-Transcript
Exit $errorCode
